SoundEngine
3x oscillators
1x noise generator
2x ring modulators
Waveforms include:Square, sine, tri, sawtooth, pulse, 9x saw:pulse combinations.
20x digital waveforms
36x wavetables
Up to 18 note polyphony (dynamic voicing)
Filter types
2x filters per patch
low pass no resonance 6dB per octave
low pass 12dB
low pass 18dB
low pass 24dB
band pass 6:6
band pass 6:12
band pass 12:6
band pass 6:18
band pass 18:6
band pass 12:12
high pass no resonance 6dB per octave
high pass 12dB
high pass 18dB
high pass 24dB
Inputs, Outputs, rear panel
・XLR dynamic mic input
・1x 1/4 jack inputs
・2x 1/4 jack outputs
・1x 1/4 jack headphone output
・Sustain pedal on 1/4 jack input
・MIDI in/out
・USB/DC/OFF power select switch
・12 volt power input
・USB port
・Kensington Lock port
